Vitrified bond CBN grinding wheel---Internal grinding

Typical applications include steering pump and compressor, bearing races, injection nozzles, hydraulic lifter, gear bores and many others. It can support high precision NC CBN Internal grinding machines.

FEPA Code	D	T	H
1A8	4	5	1.5
1A8	6	8	2
1A8	6	10	2
1A8	10	6	3
1A8	10	8	3
1A8	10	10	3
1A8	12	8	4
1A8	12	10	4
1A8	15	10	4
1A8	15	12	4
1A8	18	10	6
1A8	18	12	6
1A8	20	10	6.8
1A8	20	15	6.8
1A8	20	20	6.8
1A8	22	15	8
1A8	22	20	8
1A8	25	15	8.13
1A8	25	20	8.13
1A8	28	15	8
1A8	28	20	8
1A8	28	22	8
1A8	30	15	10
1A8	30	20	10
1A8	32	10	12
1A8	32	15	12
1A8	32	20	12
1A8	35	10	12.15
1A8	35	12	12.15
1A8	40	15	15
1A8	40	25	15
1A8	45	50	30

Order example:	PEPA code	D	T	H	X	Abrasive	Grain size	Bond	Concentration	Grade
Vitrified bond	1A8	4	5	1.5		CBN	120	V	150	N
